Overview
Quick Details | |
Lamp Power: | 50/75/100/150/200W |
Application: | widely used in road lighting for trunk roads,secondary trunk roads,branch roads,factories,schools,gardens,city squares,parks,courtyards,etc. |
Color Temperature(CCT): | 2700k-6500k optional |
Color Rendering Index(Ra): | >70 |
LED Type: | Lumileds 3030SMD |
Driver Brand: | Mean Well / Inventronics |
Smart Functions: | dimming/DALl /ZIGBEE intelligent control |
Lamp Luminous Efficiency(lm/w): | 140LM/W±5% |
Input Voltage(V): | AC100-277V / 50/60HZ |
Working Lifetime(Hour): | 70000 |
Beam angle: | T2M/T3M/T4M/90° |
Protection: | IP66 |
Working Temperature(℃): | -70 |
Lamp Body Material: | Die-cast Aluminum Alloy+PC lens |
Certification: | CE, RoHS,SASO |
Warranty: | 5-Year |
Specification
Model | UNK-SL050H2 | UNK-SL075H2 | UNK-SL100H2 | UNK-SL150H2 | UNK-SL200H2G |
Power | 50W | 75W | 100W | 150W | 200W |
Lumen | 7000 lm±5% | 10500 lm±5% | 14000 lm±5% | 21000 lm±5% | 28000 lm±5% |
lnput Voltage | AC100-277V 50/60Hz | ||||
Eficacy | 140Lm/W±5% | ||||
CRl | T2M/T3M/T4M/90° | ||||
THD | <20% | ||||
IK/IP | IP66/IK08 | ||||
Light Source | Lumileds SMD 3030 | ||||
Body Color | Light grey(can custom to other colors) | ||||
Anti-surge level | 6KV/10KV/15KV/20KV optional | ||||
Radiator Material | Aluminum Alloy | ||||
Storage Temperature | -40℃~70℃ | ||||
Operating Temperature | -25℃~45℃ | ||||
Beam Angle | T2M/T3M/T4M/90° | ||||
Smart Function | dimming/DALl dimming/ZIGBEE intelligent control | ||||
Lifespan | 70000Hrs |
